Specifications
Order Number:
| model & size | color temp | finish | led watts | led lumens | delivered lumens |
|---|---|---|---|---|---|
| WS-W48616 - 16" | 3000K | BK - Black | 12W | 1000 | 255 |
| WS-W48616 - 16" | 3000K | BZ - Bronze | 12W | 1000 | 255 |
| WS-W48620 - 20" | 3000K | BK - Black | 18W | 1600 | 519 |
| WS-W48620 - 20" | 3000K | BZ - Bronze | 18W | 1600 | 519 |
| WS-W48625 - 25" | 3000K | BK - Black | 22W | 1800 | 605 |
| WS-W48625 - 25" | 3000K | BZ - Bronze | 22W | 1800 | 605 |
Features
- Delivered Lumens: 605lm
- 3000K
- CRI: 90
- Power: 12W, 18W, 22W
- Input: 120 VAC, 277 VAC, 50/60Hz
- ELV Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Aluminum hardware with etched glass lens
- Minimal mounting hardware for easy installation
- Light engine is factory sealed for maximum protection from the elements
- Weather resistant powder coated finish
- ACLED driverless technology
- Can be mounted on wall vertically or upside down
- For 277V special order, add an "F" before the finish: WS-W48625F-BZ
Line Drawing
