Specifications Limited Availability, Consult Factory
Limited Availability, Consult Factory
Order Number:
| model & size | color temp | finish | led watts | led lumens | delivered lumens |
|---|---|---|---|---|---|
| WS-40615 - 15" | 3000K | SN - Satin Nickel | 20W | 1482 | 887 |
Features
- Delivered Lumens: 887lm
- 2700K, 3000K, 3500K
- CRI: 90
- Power: 20W
- Input: 120-277V, 50/60Hz
- ELV Dimming: 100-10%
- Rated Life: 55000 Hours
- Construction: Aluminum hardware with etched opal glass diffuser
- Conversion plate included
- Trimless spackle cover available for 4" square junction box recessed in drywall thicknesses of 1/2", 5/8", 1", and 1-1/4"; accessory not included and can be ordered separately (model# CP-TL-WT)
- Driver installed within the Junction Box, driver dimension: 2.8" x 1.3" x 1.2"
- For alternate color temperature, special order adding -27 or -35: WS-40615-35-SN
Line Drawing
