Specifications
Order Number:
| system type & voltage | model | color temp & cri | lumens | cbcp | finish |
|---|---|---|---|---|---|
| H - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | BK - Black |
| H - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | BN - Brushed Nickel |
| H - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | DB - Dark Bronze |
| H - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | WT - White |
| J - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | BK - Black |
| J - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | BN - Brushed Nickel |
| J - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | DB - Dark Bronze |
| J - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | WT - White |
| L - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | BK - Black |
| L - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | BN - Brushed Nickel |
| L - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | DB - Dark Bronze |
| L - 120 VAC | 7011 | 930 - 3000K - 90 | 17°: 890 / 30°: 855 / 50°: 830 | 17°:4972 / 30°:1961 / 50°:789 | WT - White |
Features
- Delivered Lumens: 890lm
- CBCP: 4972
- 3000K
- CRI: 90
- Power: 11W
- Input: 120 VAC, 50/60Hz
- ELV Dimming: 100-10%
- TRIAC Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Die-cast aluminum with baffled front cover for glare control
- 3 beam angle options included: 50° beam film pre-installed, interchangeable 30° film supplied, remove film for 17° spot beam
- Integral driver and high output COB LED
- Outperforms halogen 65W MR16
- 350° horizontal and 90° vertical aiming
- Driver concealed within the fixture
Line Drawing
