Specifications
Order Number:
| model & size | color temp | finish | led watts | led lumens | delivered lumens |
|---|---|---|---|---|---|
| PL-11017 - 17" | 3000K | BK - Black | 18W | 569 | 380 |
| PL-11017 - 17" | 3000K | BN - Brushed Nickel | 18W | 569 | 380 |
| PL-11025 - 25" | 3000K | BK - Black | 21W | 825 | 544 |
| PL-11025 - 25" | 3000K | BN - Brushed Nickel | 21W | 825 | 544 |
| PL-11033 - 33" | 3000K | BK - Black | 28W | 1072 | 747 |
| PL-11033 - 33" | 3000K | BN - Brushed Nickel | 28W | 1072 | 747 |
| PL-11042 - 42" | 3000K | BK - Black | 30W | 1618 | 1000 |
| PL-11042 - 42" | 3000K | BN - Brushed Nickel | 30W | 1618 | 1000 |
Features
- Delivered Lumens: 1000lm
- 3000K
- CRI: 90
- Power: 18W, 21W, 28W, 30W
- Input: 120-277V, 50/60Hz
- ELV Dimming: 100-10%
- 0-10V Dimming: 100-10%
- TRIAC Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Aluminum hardware with acrylic diffuser
- Light source rotates 150 degrees
- Simple, elegant slim profile design
- Driver conceals within the canopy
- Conversion plate for 4” J box included.
- Trimless spackle cover available for 4" square junction box recessed in drywall thicknesses of 1/2", 5/8", 1", and 1-1/4"; accessory not included and can be ordered separately (model# CP-TL-WT)
- Driver concealed within the canopy
Line Drawing
