Specifications
Order Number:
| model & size | color temp & cri | finish | watt | led lumens | delivered lumens | title 24 |
|---|---|---|---|---|---|---|
| WS-W15708 - 8" | 3000K - 90 | BK - Black | 12W | 1000 | 314 | Yes |
| WS-W15708 - 8" | 3000K - 90 | BZ - Bronze | 9W | 750 | 315 | |
| WS-W15710 - 10" | 3000K - 90 | BK - Black | 15W | 1200 | 484 | Yes |
| WS-W15710 - 10" | 3000K - 90 | BZ - Bronze | 11.5W | 1200 | 560 |
Features
- Delivered Lumens: 560lm
- 3000K
- CRI: 90
- Power: 11.5W, 12W, 15W, 9W
- Input: 120 VAC, 50/60Hz
- ELV Dimming: 100-10%
- Rated Life: 54000 Hours
- Construction: Aluminum hardware with glass diffuser
- Weather resistant powder coated finishes
- Light engine is factory sealed for maximum protection from the elements
- Heavy aluminum shade provides great glare cutoff
- Title 24 may not be available for all finishes, check for availability
- ACLED driverless technology
Line Drawing
